This Toyota Tundra gauge cluster is programmed for non-flex fuel trucks. If you install a flex fuel cluster in a non-flex fuel truck your fuel gauge will read much higher than it should and you may run out of fuel. The fuel pump and sending unit is different.
This item is one Toyota Tundra Optitron instrument gauge cluster for 2007, 2008, 2009, 2010, 2011, 2012, and 2013 Limited models. Although this instrument cluster is removed from a Limited model and has a transmission temperature gauge, it can be installed in any 2007-2013 Toyota Tundra regardless of the instrument cluster originally installed.
You will receive one of these part numbers: 83800-0CL50, 83800-0C570, 83800-0CA40, 83800-0CA50, 83800-0CF10, 83800-0CF11
You will need to install the Limited combo switch which has Info/Select Reset/Setup on it to scroll through the cluster screen. We do not sell the switch. You can buy it cheaper than we can sell it on any other marketplace.
If you have sonar/parking sensors then you need to buy: 84977-0C090
If you do not have parking sensors then you need to buy: 84977-0C020
Tips:
- If your distance to empty and fuel data display is blank then your truck is missing the CAN lines going to the cluster. Check your cluster connector for a yellow wire and a white wire on pins 21 and 22. If they are missing you will need to add them from your body ECU to the optitron cluster.
- If you are installing this cluster on a 4.0L 1GR-FE or a truck that does not have an oil pressure gauge already then you must disconnect or change the oil pressure switch (83530-60020) to an oil pressure sender (83520-60051). If you don’t you may damage the cluster.
Common issues that can be solved with a replacement Toyota Tundra Optitron instrument gauge cluster include:
- Total power loss
- Gauges not working or moving correctly
We also offer a 2007 – 2013 Toyota Tundra Instrument Cluster SR5 with Transmission Temperature for customers that wish to stick with the original orange backlighting look!
